Pipe Clamp type 7512

Pipe Clamp. Two-part Pipe Clamp. Model 7512. Used for pipe support.
Surface: Hot-dip-galvanized.
Material certificate type 3.1. can be purchased - in which case this must be stated in the comment field when submitting the order.

Product specifications

Product type	Pipe Clamp Type 7512
Supplier name	Lehaka
Model	Pipe Clamp
Standard (Norm)	7512
Material	Steel (S355/J2)
Surface treatment	Hot-dip galvanized (FZV)
Application	Bearing clamp for fixing pipes
Remark	Delivered excl. Nuts
Certifikat	3.1. Certificate can be delivered (optional purchase)
Unit	Set
Customs Code	73089098

Technical Data

Add to order

Name

Thread/bolt

Pipe size (mm)

Pipe diameter (")

Dimension (mm)

Stock status

Price

Pipe Clamp WS Type 7512 Galvanized - 34mm
# 7910223034

Thread/bolt M10x25

Pipe size (mm) 33,7

Pipe diameter (") 1”

Dimension (mm) 40x5

Login needed

Pipe Clamp WS Type 7512 Galvanized - 38mm
# 7910223038

Thread/bolt M10x30

Pipe size (mm) 38

Pipe diameter (")

Dimension (mm) 40x5

Login needed

Pipe Clamp WS Type 7512 Galvanized - 42mm
# 7910223042

Thread/bolt M10x30

Pipe size (mm) 42,4

Pipe diameter (") 1 ¼”

Dimension (mm) 40x5

Login needed

Pipe Clamp WS Type 7512 Galvanized - 49mm
# 7910223049

Thread/bolt M10x30

Pipe size (mm) 48,3

Pipe diameter (") 1 ½”

Dimension (mm) 40x5

Login needed

Pipe Clamp WS Type 7512 Galvanized - 60mm
# 7910223060

Thread/bolt M10x30

Pipe size (mm) 60,3

Pipe diameter (") 2”

Dimension (mm) 40x5

Login needed

Pipe Clamp WS Type 7512 Galvanized - 76mm
# 7910223076

Thread/bolt M10x30

Pipe size (mm) 76,1

Pipe diameter (") 2 ½”

Dimension (mm) 40x5

Login needed

Pipe Clamp WS Type 7512 Galvanized - 89mm
# 7910223089

Thread/bolt M10x30

Pipe size (mm) 88,9

Pipe diameter (") 3”

Dimension (mm) 40x5

Login needed

Pipe Clamp WS Type 7512 Galvanized - 108mm
# 7910223108

Thread/bolt M16x45

Pipe size (mm) 108

Pipe diameter (")

Dimension (mm) 50x6

Login needed

Pipe Clamp WS Type 7512 Galvanized - 114mm
# 7910223114

Thread/bolt M16x45

Pipe size (mm) 114,3

Pipe diameter (") 4”

Dimension (mm) 50x6

Login needed

Pipe Clamp WS Type 7512 Galvanized - 133mm
# 7910223133

Thread/bolt M16x45

Pipe size (mm) 133

Pipe diameter (")

Dimension (mm) 50x6

Login needed

Pipe Clamp WS Type 7512 Galvanized - 140mm
# 7910223140

Thread/bolt M16x45

Pipe size (mm) 139,7

Pipe diameter (") 5”

Dimension (mm) 50x6

Login needed

Pipe Clamp WS Type 7512 Galvanized - 159mm
# 7910223159

Thread/bolt M16x45

Pipe size (mm) 159

Pipe diameter (")

Dimension (mm) 50x6

Login needed

Pipe Clamp WS Type 7512 Galvanized - 168mm
# 7910223168

Thread/bolt M16x45

Pipe size (mm) 168,3

Pipe diameter (") 6”

Dimension (mm) 50x6

Login needed

Pipe Clamp WS Type 7512 Galvanized - 194mm
# 7910223194

Thread/bolt M16x45

Pipe size (mm) 193,7

Pipe diameter (")

Dimension (mm) 50x6

Login needed

Pipe Clamp WS Type 7512 Galvanized - 219mm
# 7910223219

Thread/bolt M20x60

Pipe size (mm) 219,1

Pipe diameter (") 8”

Dimension (mm) 60x8

Login needed

Pipe Clamp WS Type 7512 Galvanized - 273mm
# 7910223273

Thread/bolt M20x60

Pipe size (mm) 273

Pipe diameter (") 10”

Dimension (mm) 60x8

Login needed

Pipe Clamp WS Type 7512 Galvanized - 324mm
# 7910223324

Thread/bolt M20x60

Pipe size (mm) 323,9

Pipe diameter (") 12”

Dimension (mm) 60x8

Login needed

Pipe Clamp type 7512
