Comege Foldable Mobile Aluminium Gantry Crane PADC

There is often a need for mobile lifting equipment. When all installation options have been exhausted, the PADC gantry crane is an ideal solution. Lightness and robustness are the advantages of an aluminium gantry crane structure.

The PADC is mounted on wheels for indoor or outdoor use. It can be moved under load on a smooth, clean surface.

Light construction:

- Bolted joints
- Easy assembly with 8 bolts between legs and beam
- Assembly requires 1 to 3 people, depending on the model
- Flexible movement thanks to the light weight
- Hollow-section gantry beam
- Trolley included
- The height under the beam can be adjusted by one person
- Can be taken apart into 3 parts
- The feet fold up for transport
- White polyamide wheels, 2 of them with brakes
- Maximum lifting speed = 8 m/min.
- Protection: polyester powder coating 60 microns C2. RAL 9006 finish.

Options:

- Polyurethane-banded wheels
- 2 extra braked wheels
- Non-swivel wheels
- Power cable for the hoist
- Size can be adapted to your needs on request
- Electric or manual hoist
