Rundsling TLX200 WLL 20T orange 5 / 2.5m

Round sling with the capacity shown in its colour

The round sling has a WLL of 20,000 kg in a straight lift. This variant has a circumference of 5 m and a length of 2.5 m and is marked to EN 1492. The orange colour follows the colour code for round slings with WLL 20 t.

• WLL 20,000 kg in a straight lift
• Circumference 5 m, length 2.5 m
• Material: polyester
• Safety factor 7:1
• Operating temperature from -40 °C to +100 °C

How to read the capacity for other hitches

The WLL applies to a straight lift. In a choked lift the WLL is 16,000 kg, and in a basket hitch with vertical legs 40,000 kg. In an angled basket hitch the value decreases with the angle, and the full table is in the round sling user manual. The sling can be used for various lifting tasks within the stated temperature range. Choose circumference and length from the dimensions of the load and the hitch you intend to use. Inspect the sling for damage before and after each lift, and remove it from use if damage is visible.
